Focal Shape Twin Dual 5 inch Powered Studio Monitor with Passive Radiators

Product Description

Shape Twin 2.5-way monitoring speaker

Made in France

Shape Twin is the flagship of the Shape line. This monitoring loudspeaker features excellent readability across the entire audio spectrum, combined with extended low-frequency response and a high SPL (110.5 dB) for its size. Equipped with two 5″ (13 cm) Flax cone woofers reproducing the 40 Hz- 2.5 kHz register, it shines in terms of perShapence and design.

REFERENCE MONITOR

Flax membranes on the woofers, an aluminum-magnesium “M” profile tweeter, three Class AB amplifiers, two 21 cm passive radiators: Shape Twin is a work tool with a vast and precise stereophonic image. A must-have for any recording studio!

COMPACT DESIGNS

Its compactness makes it easy to integrate, even in the smallest of spaces. Its 2.5-way d’Appolito design offers a decisive advantage in terms of bass and low-midrange register control, always critical in a small space. This monitor expresses its full potential from a listening distance of 1 m.

FUNCTIONAL

XLR and RCA inputs, adjustable bass and treble levels, adaptable 160 Hz crossover, disengageable high-pass crossover are just some of the functions and settings available.

STYLE AND DISCRETION

Alongside an MDF cabinet body partly covered with real walnut veneer, Shape Twin is very stylish. Compact, it is as discreet as it is flexible in its positioning, thanks to the mounting inserts.

Specifications

Sound – Acoustics

Product type : 2.5-way monitor
Loudspeakers :
• Woofer : 2 x 5″ Flax membrane
• Tweeter : 1″ Aluminium-Magnisium M shaped dome
Frequency response (+/- 3dB) :
40 Hz – 35 kHz
Maximum SPL (peak@1m) :
110 dB

Sound – Electronics

Inputs :
• XLR: symmetrical 10 kOhms
• RCA: asymmetrical 10 kOhms with compensanted sensitivity
High frequency amplifier : 50 W, class AB
Mid-range and low frequency amplifier : 2 x 80 W, class AB
Indicators and controls :
• HPF, LF Shelv, LMF EQ, HF Shelv

Design

Height : 47.8 cm
Width : 21.1 cm
Depth : 27.9 cm
Weight : 11 kg
