Roland SP-404MKII Linear Wave Sampler

Keterangan Produk

The ultimate SP is here.
Roland SP samplers are the bona fide kings of performance-based beatmaking, celebrated for their distinctive sound and ability to create rapid-fire beats anywhere, anytime. Carefully refined through community feedback and extensive research and development, the SP-404MKII is the ultimate SP sampler. It’s faster and better than ever, with a vivid OLED display, expressive new pads, expanded effects, fluid sequencing and sampling, and a massive library of authentic sounds to inspire your music.

FEATURES

Vivid OLED display for visual waveform editing, full menu access, and more
17 velocity-sensitive, RGB pads with no-click design for smooth playability
Faster workflow with quick startup and load times, 16 GB internal storage, low-latency pads, and rapid sample editing
Compact, ultra-lightweight design (2.4 lbs. / 1.1 kg) with versatile power options: USB-C, mobile battery (via USB-C port), six AA batteries, or AC adaptor
Extensive onboard effects, including SP classics like Vinyl Simulator and DJFX Looper plus new Lo-fi, Cassette Simulator, and Resonator
Dedicated Vocoder, Auto Pitch, Harmony, Guitar Amp Simulator, and Anti-Feedback processing for the mic/guitar input
32-voice polyphony, 160 samples per project, and 16 internal projects for expanded programming possibilities
Blazing onboard sample editing with real-time or auto-chop mode, auto BPM detect, envelope, pitch shift, and resampling for layering sounds and phrases
Pre-loaded sound library with 144 high-quality, professionally recorded samples and patterns
Extensive customization options with removable metal faceplate, downloadable outline template, multiple screensavers, and personalized startup logos
Upgraded I/O includes 1/4-inch line in/out, 1/4-inch mic/guitar input, 1/4-inch and 1/8-inch headphones outputs, and 1/8-inch TRS MIDI in/out
New resampling workflow for re-recording with various effects for detailed sound design
Audio capture and streaming supported with mobile devices and computers via USB-C*
Skip Back Sampling to automatically capture up to 40 seconds of audio from your last performance
VariPhrase encoder for high-quality timestretching of pitch and speed parameters
Bus FX for layering multiple effects, with customizable routing for creating intricate sound textures
Adjust quantization before or after recording and tweak shuffle percentage across multiple note resolutions to customize swing
Pattern sequencer with the ability to create full songs with BPM per bank, ideal for running backing tracks or programming performances
Sequence patterns with real-time loop recording or TR-REC step input
Motion recording for capturing dynamic changes to effect parameters, sub step, pitch, and velocity
Set shuffle and time signature (1/4–7/4) per pattern
Chain patterns for automatic playback and use Pad Link to trigger up to four samples with a single press
Adjustable delay on the MIDI clock output for tight sync with external instruments
DJ Mode enables new live performance approaches with the ability to mix two audio files or patterns, manipulate eight cue points per sample, adjust fader curves, sync external MIDI instruments, and more
SP-404MKII standalone editor app for macOS and Windows provides direct sample access, detailed waveform editing, sample management, pad assignment, and import of MIDI files and legacy SP-404SX and SP-404A projects
SP-404MKII editor app also available as an AU/VST3 plug-in for music production software on macOS

SPECIFICATIONS

Maximum Polyphony
32 voices

Recordable Data
Samples = 2,560 (16 samples x 10 banks x 16 projects, stored in internal storage)
Patterns = 2,560 (16 patterns x 10 banks x 16 projects, stored in internal storage)

Internal storage
Size: 16 GB
*Including preload data

Maximum sampling time
16 minutes (approximately 185 MB per sample)

Skip Back Sampling
Maximum 40 seconds (always records LINE OUT signal independently of sampling/resampling)

Internal Data Format
16-bit linear

Import Format
WAV, AIFF, MP3
*SP-404MKII APP supports WAV, AIFF, MP3, FLAC, M4A.

Sampling frequency
48kHz

Pattern Sequencer
Resolution: 480 ticks, quarter note
Pattern length: 1 to 64 bars (variable during recording)
Recording methods: real-time loop recording, TR-REC step sequencing

Effects
Multi-effects: 41 types
Input effects: 17 types

Pad
16 pads 1 sub pad (Velocity-sensitive pad)

Controller
Control knobs x 3

Display
Graphic OLED display

External Storage
SD card (sold separately) for backup, restore, import, and export functions (SDHC compatible)

Connection terminals
PHONES jacks: 1/4-inch phone type, Stereo miniature phone type
LINE OUT (L/MONO, R) jacks: 1/4-inch TRS phone type (impedance balanced)
LINE IN (L/MONO, R) jacks: 1/4-inch phone type
MIC/GUITAR IN jacks: 1/4-inch TRS phone type (for MIC), 1/4-inch phone type (for GUITAR)
MIDI (IN, OUT) jack: Stereo miniature phone type
USB terminal: USB Type-C (Audio, MIDI)
DC IN terminal

Power Supply
AC adaptor
USB bus power supply (USB Type-C port, 1.5 A ormore)
Ni-MH batteries (AA, HR6)(sold separately) x 6
Alkaline battery (AA, LR6)(sold separately) x 6

Current Draw
1,100 mA (AC adaptor)
1,500 mA (USB bus power)

Expected battery life under continuous use
Alkaline battery: Approx. 2.5 hours
Ni-MH battery: Approx. 3.5 hours
*This can vary depending on the specifications of the batteries, capacity of the batteries, and the conditions of use.

Accessories
Quick start
“Read Me First” leaflet
Roland User Registration Card
AC adaptor
Warranty card

Options (sold separately)
TRS/MIDI connecting cable: BMIDI-5-35, BMIDI-1-35, BMIDI-2-35, BCC-1-3535, BCC-2-3535
